Self Loading All-in-One Stacker Semi-Electric Lifting Capacity 1000 kg, 1.6 m Lifting Height JDESESLS-1016
Model: JDESESLS-1016
Semi-Electric Self-Loading Stacker JDESESLS-1016 with 1 ton capacity and 1.6 m lift height. View specifications and request a quote from JDE.
- Capacity
- 1 ton
- Lift height
- 1.6 m
- Power type
- Semi-electric
- Operation type
- Self-loading
- Battery type
- Lithium
Get a quote in 1 minute
Share your phone number and requirement. Our team will call you back with options and a quotation.
Full specifications
| Brand | JDE |
|---|---|
| Type | Semi-Electric Self-Loading Stacker |
| Model | JDESESLS-1016 |
| Operation Type | Walking Type |
| Forward & Backward | Manual |
| Lifting Up & Down | Electric |
| Capacity | 1000 kg |
|---|---|
| Load Center Distance | 500 mm |
| Fork Lift Height | 1600 mm |
| Fork Outer Spacing | 685 mm |
|---|---|
| Fork Length | 1195 mm |
| Fork Starting Height from the Ground | 81 mm |
| Vehicle Length | 1650 mm |
| Body Thickness | 409 mm |
| Body Width | 658 mm |
| Front Track | 518 mm |
| Single Fork Width | 253 mm |
| Minimum Turning Radius | 1173 mm |
| Drive Wheel Size | Ø 250 x 74 mm |
|---|---|
| Load Wheel Size | Ø 80 x 60 mm |
| Middle Wheel | Ø 65 x 30 mm |
| Wheel Base | 974 mm |
| Motor | DC 0.6 kW |
|---|---|
| Lift Motor | DC 2.2 kW |
| Battery | Lithium Battery (48 V) |
| Battery Capacity | 15 Ah |
| Maximum Driving Speed (Turtle Speed) | 0.5 km/h |
|---|---|
| Maximum Driving Speed (Full Load) | 3.0 km/h |
| Battery Weight | 5 kg |
|---|---|
| Overall Weight (Include Battery) | 382 kg |
Description
JDE Semi-Electric Self Loading Stacker 1000 kg with Lifting Height 1.6 m is a professional-grade stacking device offering a 1000 kg capacity with a 500 mm load center distance, 685 mm fork outer spacing, 1195 mm fork length, and 81 mm fork starting height.
It offers a maximum driving speed of 3.0 km/h and lithium battery 48 V with 15 Ah capacity.
It has a robust total weight of 382 kg and features a 0.6 kW DC motor and 2.2 kW DC lift motor.
It has a maximum driving speed (full load) of 3.0 km/h, a fork starting height from the ground of 81 mm, and a maximum turning radius of 1173 mm.
