Self Loading All-in-One Stacker Fully Electric Lifting Capacity 1000 kg, 1.6 m Lifting Height JDEFESLS-1016
Model: JDEFESLS-1016
Fully Electric Self-Loading Stacker JDEFESLS-1016 with 1 ton capacity and 1.6 m lift height. View specifications and request a quote from JDE.
- Capacity
- 1 ton
- Lift height
- 1.6 m
- Power type
- Fully electric
- Operation type
- Self-loading
- Battery type
- Lithium
Get a quote in 1 minute
Share your phone number and requirement. Our team will call you back with options and a quotation.
Full specifications
| Brand | JDE |
|---|---|
| Type | Fully Electric Self-Loading Stacker |
| Model | JDEFESLS-1016 |
| Operation Type | Walking Type |
| Forward & Backward | Electric |
| Lifting Up & Down | Electric |
| Capacity | 1000 kg |
|---|---|
| Load Center Distance | 500 mm |
| Fork Lift Height | 1600 mm |
| Fork Outer Spacing | 570 mm |
|---|---|
| Fork Length | 1150 mm |
| Fork Starting Height from the Ground | 81 mm |
| Vehicle Length | 1730 mm |
| Body Thickness | 409 mm |
| Overall Width | 920 mm |
| Front Track | 518 mm |
| Single Fork Width | 195 mm |
| Minimum Turning Radius | 1173 mm |
| Drive Wheel Size | Ø 250 x 74 mm |
|---|---|
| Load Wheel Size | Ø 80 x 60 mm |
| Middle Wheel | Ø 65 x 30 mm |
| Wheel Base | 974 mm |
| Motor | DC 0.6 kW |
|---|---|
| Lift Motor | DC 2.2 kW |
| Battery | Lithium Battery (48 V) |
| Maximum Driving Speed (Turtle Speed) | 0.5 km/h |
|---|---|
| Maximum Driving Speed (Full Load) | 3.0 km/h |
| Battery Weight | 5 kg |
|---|---|
| Overall Weight (Include Battery) | 382 kg |
Features
- The durable construction and lithium battery provide reliability and a weight of only 5kg
- This stacker is perfect for warehouses and factories
Description
JDE Fully Electric Self Loading Stacker 1000 kg with Lifting Height 1.6 m JDEFESLS-1016 is a highly durable and powerful stacker suitable for various commercial purposes.
Its maximum load capacity of 1000 kg and load center distance of 500 mm allows for efficient transportation of heavy materials.
It has an operating type of walking-type, drive wheel size of Ø 250 x 74 mm, load wheel size of Ø 80 x 60 mm, and a maximum driving speed of 3.0 km/h.
The stacker is powered by a DC 0.6 kW motor and a DC 2.2 kW lift motor.
The durable construction and lithium battery provide reliability and a weight of only 5 kg.
This stacker is perfect for warehouses and factories.
