JDE Self-Propelled Scissor Lift Platform 227 kg Capacity 14 m Lifting Height JDESPSLP-1422
Model: JDESPSLP-1422
Self-Propelled Scissor Lift Platform JDESPSLP-1422 with 227 kg capacity and 14 m lift height. View specifications and request a quote from JDE.
- Capacity
- 227 kg
- Lift height
- 14 m
- Power type
- Fully electric
Get a quote in 1 minute
Share your phone number and requirement. Our team will call you back with options and a quotation.
Full specifications
| Brand | JDE |
|---|---|
| Type | Self-Propelled Scissor Lift Platform |
| Model No. | JDESPSLP-1422 |
| Maximum Working Angle | 1.5 / 3° |
| Working Height | 16 m |
|---|---|
| Platform Height | 14 m |
| Loading Capacity | 227 kg |
| Loading Capacity of Extend Platform | 113 kg |
| Max. Climb Capacity | 25% |
| Platform Size | 2640 x 1130 mm |
|---|---|
| Outlook Size | 2390 x 1160 x 2600 mm |
| Extend Platform Size | 900 mm |
| Minimum Ground Clearance | 106 / 29 mm |
| Wheelbase | 2240 mm |
|---|---|
| Tyre | Ø 381 x 127 mm |
| Lifting / Drive Motor | 24 V / 4.5 kW |
|---|---|
| Storage Battery | 4 x 6 V / 240 Ah |
| Charger | 24 V / 30A |
| Speed (Gather / Lifting) | 3.5 Km / 0.8 Km/h |
|---|
| Weight | 3450 kg |
|---|
