JDE Hydraulic Scissor Lift Table 1000 kg PNXLTX-1000 – JDE

JDE Hydraulic Scissor Lift Table 800 kg JDELTX-800

Model: JDELTX-800

Table Lifter / Lifting Table / Single Scissor Lift Table JDELTX-800 with 800 kg capacity and 580 mm lift height. View specifications and request a quote from JDE.

Capacity
800 kg
Lift height
580 mm
Power type
Manual
Request a Quote Call WhatsApp

Full specifications

General
BrandJDE
TypeTable Lifter / Lifting Table / Single Scissor Lift Table
Model No.JDELTX-800
Capacity & lift
Capacity800 kg
Max. Height1000 mm
Lifting Height580 mm
ScissorSingle Scissor
Dimensions
Min. Height420 mm
Platform Size855 x 510 x 55 mm
Distance to Handle996 mm
Overall Length1150 mm
Performance
Step Time When Lifting≤70

Features

  • Standard powder coat finish which is resistant to normal corrosion
  • Heavy duty and reinforced construction for greatest strength and durability
  • The design structure is reasonable, safe and stable, and reliable for use
  • It is used for convenience and flexibility to lift materials

Description

Standard powder coat finish which is resistant to normal corrosion.

Heavy duty and reinforced construction for greatest strength and durability.

The design structure is reasonable, safe and stable, and reliable for use.

It is used for convenience and flexibility to lift materials.

JDE Hydraulic Scissor Lift Table 800 kg JDELTX-800 is designed to lift heavy material with less effort.

This load lifter can turn in a radius of 1260 mm and has a lowered height of 420 mm.

It has a load capacity of 800 kg.

Its platform size is 1000 x 510 x 55 mm with a safety lock.
