JDE Hand Pallet Truck 5 ton With Fork Length 1210x685 mm PNXPT-50 – JDE

JDE Hand Pallet Truck 3 ton JDEPT30

Model: JDEPT30

Hand Pallet Truck JDEPT30 with 3 ton capacity. View specifications and request a quote from JDE.

Capacity
3 ton
Power type
Manual
Request a Quote Call WhatsApp

Full specifications

General
BrandJDE
TypeHand Pallet Truck
Model No.JDEPT30
Pump FinishPowder Coating
Piston Dia.35 mm
Quick LiftYes
Sharp EdgesNo
Capacity & lift
Capacity3000 kg
Overall Raise From Ground>200 mm
Lifting Capacity (Per Stroke)10 mm
Dimensions
Fork Length1200 mm
Overall Fork Width685 mm
Single Fork Width160 mm
Ground Clearance30 mm
Total Height1200 mm
Turning Radius1265 mm / 210°
Lowered Fork Height90 mm
Overall Length1550 mm
Sheet Thickness4 mm
Distance Between Forks370 mm
Wheels & brakes
Rollers Size80 x 70 mm
Steering Wheel Size180 x 50 mm
RollersNylon
Wheel TypeNylon
Entry / Exit RollerYes
Performance
Proportional LoweringYes
Weight
Net Weight73 kg

Features

  • Hand pallet trucks are specially designed for smooth horizontal movement inside the operating areas
  • Complete pump design with reliable leak-proof pump eliminating maintenance and extending the service time
  • Fork Lowering speed is controllable, operated by hand control
  • Standard powder coat finish which is resistant to chips and normal corrosion

Description

Hand pallet trucks are specially designed for smooth horizontal movement inside the operating areas.

Complete pump design with reliable leak-proof pump eliminating maintenance and extending the service time.

Fork Lowering speed is controllable, operated by hand control.

Standard powder coat finish which is resistant to chips and normal corrosion.

It features a steering wheel that measures 200 mm wide and 55 mm thick, and the fork width is 685 mm.

The lifting height per stroke is 12 mm, which can be lowered to 75 mm.

It is ideal for light loads, with the capacity to support up to 3000 kg.

Its turning radius is 1265 / 210° Degree and the distance between forks is 350 mm.

Frequently asked questions
