JDE Electric Pallet Truck 2 ton JDEEPT-20SD
Model: JDEEPT -20SD
Electric Pallet Truck JDEEPT -20SD with 2 ton capacity and 200 mm lift height. View specifications and request a quote from JDE.
- Capacity
- 2 ton
- Lift height
- 200 mm
- Power type
- Fully electric
Get a quote in 1 minute
Share your phone number and requirement. Our team will call you back with options and a quotation.
Full specifications
| Brand | JDE |
|---|---|
| Model No. | JDEEPT -20SD |
| Type | Electric Pallet Truck |
| Operate Type | Stand Up |
| Drive Unit | Electric |
| Max. Grade Ability (Load/Unload) | 6/15 % |
| Rated Capacity | 2000 kg |
|---|---|
| Load Center | 600 mm |
| Max. Lift Height | 200 mm |
| Fork Ground Clearance | 85 mm |
|---|---|
| Total Length | 1856 mm |
| Fork Dimensions(L/W/H) | 1150X180X50 mm |
| Fork Width | 570 / 685 mm |
| Turning Radius | 1530 mm |
| Wheelbase | 1495 mm |
|---|---|
| Driving Wheel | Ø230x75 mm |
| Load Wheel | Ø80x70 mm |
| Balance Wheel | Ø130x55 mm |
| Balance Wheel Wheelbase | 498 mm |
| Load Wheel Wheelbase | 500/390 mm |
| Brake Type | Electro Magnetic Brake |
| Traction Motor | 1.5 kW/24 V |
|---|---|
| Lift Motor | 2.2 kW/24 V |
| Battery Volts/Ampere | 24 V/210Ah |
| Traction Speed (Load/Unload) | 5/6 Km/h |
|---|---|
| Lifting Speed (Load/Unload) | 25/30 mm/s |
| Lowering Speed (Load/Unload) | 30/25 mm/s |
| Noise | 70 dB |
| Self Weight (Without Battery) | 320 kg |
|---|---|
| Battery Weight | 200 kg |
Features
- The butterfly release electric brake ensures excellent braking performance
Description
JDE Electric Pallet Truck 2 ton JDEEPT-20SD is a reliable and efficient solution for moving heavy loads.
It features a 2000 kg rated capacity, 600 mm load center, electric drive unit with a 5/6 Km/h traction speed, and 1530 mm turning radius, allowing for quick and secure transport.
The butterfly release electric brake ensures excellent braking performance.
Its 1495 mm wheelbase provides exceptional stability for even the heaviest loads.
The driving wheel Ø230x75 mm and load wheel Ø80x70 mm ensure smooth maneuverability and the 200 mm max. lift height provides reliable accuracy.
Built for efficiency, this truck is 1856 mm in length, 730 mm in width, and features 1150X180X50 mm forks.
With its 1150x180x50 mm fork dimensions and 6/15% grade ability, this pallet truck will provide a powerful and safe lift every time.
JDE Electric Pallet Truck 2 ton JDEEPT-20SD offers a 600 mm load center and a self-weight of 320 kg.
